MR124M Basic Pneumatics Trainer Educational Equipment Demonstrational Equipment Mechatronics Training Equipment I.Product Overview 1.1 Product Description It consists of an air service unit, a pneumatic actuator, a pneumatic component group and a power valve kit. Through the trainer, you can become familiar with the basic usage of a single component. Understand and design experiments to achieve different purposes by cooperating between different components. Through the trainer, you can master its principles and control methods and cultivate the corresponding knowledge and skills of testers. It is suitable for teaching and skill training assessment of related majors 1.2 Product Features 1. No special installation requirements and power interface are required 2. Stable operation, more reliable and durable during use due to simpler gas circuit 3. Fast response speed, the response speed can reach millisecond level within the controllable range II.Performance Parameter 2.1 Technical Parameters Pneumatic indicator light: operating pressure 0.1-0.8Mpa Air compressor and air pump oil-free machine: 220V, 550W, 8L 2.2 Dimensions and Weight Dimensions: 900*400*878mm Weight:<100kg III.Product component names and function introduction 3.1 Product main part No. Name 1 Triplet 2 3/2 way button valve (often open) 3 3/2 way button valve (normally closed) 4 3/2 way knob valve 5 3/2 way knob valve 6 Pressure gauge 7 Pneumatic indicator light 8 Fast exhaust valve 9 Reunion valve 10 Gas source allocation 11 Delay valve 12 Dual pressure valve 13 Shuttle valve 14 3/2 way conversion valve (often open) 15 3/2 way conversion valve (normally closed) 16 Dual air control 5/2 way reversing valve 17 Single air control 5/2 way reversing valve 18 Single air control 3/2 way reversing valve 19 Sequential valve 20 Dual -action cylinder 21 Single-action cylinder 22 Roller -type limit switch 23 Lex leverage limit switch 3.2 Product accessories No. Name 1 Trachea 2 Trachea scissors 3 Tracheal block 4 Pneumatic T connector joint 5 Straight joint 6 Spring trachea IV.Product Configuration List No. Name Quantity 1 Triplet 1 2 Air sources 1 3 Delay valve 1 4 Dual pressure valve 1 5 Shuttle valve 1 6 3/2 way conversion valve (often open) 2 7 3/2 way conversion valve (normally closed) 1 8 Reunion valve 1 9 Fast exhaust valve 1 10 3/2 way button valve (often open) 2 11 3/2 way button valve (normally closed) 2 12 3/2 way knob valves 1 13 5/2 way knob valve 1 14 Pressure gauge 1 15 Pneumatic indicator light 2 16 Sequential valve 1 17 Single air control 3/2 way reversing valve 2 18 Single air control 5/2 way reversing valve 1 19 Dual air control 5/2 way reversing valve 3 20 Dual -action cylinder 2 21 Single -action cylinder 1 22 Roller -type limit switch 2 23 Lex leverage limit switch 2 24 air pump 1 25 trachea 50m 26 Trachea scissors 1 27 Tracheal block 10 28 Pneumatic T connector joint 5 29 Straight joint 2 30 Spring trachea 1 V.Experiment list Experiment 1 Dual -action cylinder test experiment Experiment 2 Slotting valve test experiment Experiment 3 Delay valve test experiment Experiment 4 Dual pressure valve test experiment Experiment 5 Testing of shuttle valve test experiments Experiment 6 Subvant valve test experiment Experiment 7 Dual air control 5/2 way reversing valve test experiments Experiment 8 Single air control 5/2 way reversing valve test experiments Experiment 9 Test experiment of roller -type limit switch and leverage limit switch switch
